玻璃鋼過濾器
HXP全塑袋式過濾系統是一種新型的過濾系統,具有過濾精度高,處理量大,使用、維護方便等特點。因此可廣泛應用于食品、化妝品、化工、醫療、紡織等領域。HXP全塑袋式過濾器可分為三部分:過濾容器、濾籃和濾袋。
HXP bag filter system is a new filter system. It is character with high precision, big flow, easy installation and maintenance. So it can be widely used in the field of liquid treatment: foods,cosmetic, chemistry, medicine, textile, etc. It consists of the housing, support basket ,and the filter bag..
產品優勢/Product Merits
- 1、過濾器采用FRP材質,部件一次成型, 標準化生產,更換、維修方便。
- 2、過濾器進出水口連接有4"coupling,拆裝方便,視覺美觀、整齊。
- 3、過濾器采用上部進水,濾芯受沖擊阻力小;頂部裝有排氣閥,便于過濾器中空氣排出。
- 4、過濾器底部系統與頂部濾芯定位壓緊板均采用一-體式設計,濾芯的安裝并壓緊既容易又可避免內漏現象。
- 5、過濾器封蓋與本體連接采用吊環螺絲法蘭式密封,既確保過濾器完好的密封性能,又給更換濾芯的拆裝帶來了方便和快捷且使過濾器能承受更大壓力。
- 6、過濾器為FRP材質成型,具有較強的耐腐蝕性,能用于不銹鋼不能代替的化工行業及海水淡化領域。
- 1.All the parts of this series filters are made of FRP material.
- 2.The inlet and outlet , which connected with the pipe is adopt a 4" coupling.
- 3.The distribution system of HPCF filters is distributed from top.Water is well-proportioned with small strike to cartridges and air is easy to be discharged.
- 4.The bottom system of HPCF filter is designed together as a whole with the top localizer & closure system.Cartridges are easy to be installed, push down and closed, preventing leaking inside.
- 5.The lid and the body are connected using eyebolts flange method, Ensure a good seal performance. and ensure the filter can stand higher pressure.
- 6.HPCF filter is corrosion resistant, It can be used in SS none- replace field, and seawater treatment field
